HF pvc clamshell welding machine for LED light flash lamp packaging industry

Brief introduction

This is one of the basic design of our standard high frequency welding machine. The popular model is: JC-5000S, JC-8000S, JC-10000S. It add a square hand push rotated plate with two working positions under the hf welding head. This structions Radio frequency pvc welder is good for welding small size pvc welding work. like welding margin or pvc blister. pvc clam shell for samll product packaging industry. Only need one people to operate this machine and help client safe labor cost.

Applications

radio frequency PVC blister paperboard welder hf handle self Slimming massager tool welding machine for packaging packaging industry. expert pvc blister welding machine for daliy necessarily clamshell lip balm,lip care stick,Lip Moisturize,makeup,AA battery,lipstick and hardware clamshell paperboard packaging. radio frequency pvc clam shell welding machine. Wide used for making handbag, pencil box/id card sleeve ,small spraying toys, leather products, carpet, plastic inflatable products clothes and shoes embossing tool, trademark, box, air tool, carpet, package bag, heat water bag, medical treatment articles, stationary, photo album, physical good, pvc folding box, glass box, garment logo welding and shoe upper and so on.

Specifications:

Install high Q oscillation value in the machine which is stable and reliable in output.
two working positions work alternatively to improve the production
Pneumatic press system, max pressure can up to 350KG
With heated electrode welding horn holding plate.
International standard working frequency 27/12 MHz + -0.6%.
Anti spark device with 5557,to protect machine and welding mould from over current
Working voltage can be 1/3 phases, 220V/380V, 50/60Hz + ground or customized
Electric resistances and temperature control by a thermo regulator.

PVC blister weld sample

Latest Welding Samples

Reference working video

Specifications

hf blister mold
